The Torrey Pines Logic T12-M Thermal Red Dot is ideal for search operations, hunting, commercial or home security or for evaluating energy efficiency. The lightweight Torrey Pines Logic T12-M Mini Thermal Imager, 30Hz is easy to mount on a tripod with its quick release mount. You can choose from white hot, color, black hot or NV green display schemes for different situations, prey and levels of ambient light with the Torrey Pines Logic T12-M Lightweight Mini Thermal Imager.

On‑board image processing enhancement modes

Manual and automatic NUC capability

Temperature read‑out

Battery read‑out and protection

Auto power‑save

Multiple display views: white hot / color / black hot / NV green

Flexible mounting options: Tripod / Picatinny rail / user‑handle mount and more

30Hz units are ideal for hunters and support more sophisticated domestic user needs. 9Hz units are export ready. Devices can be used in variety of search operations, firefighting and detection and other commercial applications.

Specifications

Size: 2″ x 1.8” x 1.5” (50 x 45 x 39mm)

Weight: (w/o battery) 50 g

Field-of-View: 50°

Minimum Focus Distance: 4” (.1m)

Mount: Picatiny Quick Release

Power: CR123, 3V – 8+ hours of operation

Resolution 80 x 60 pixels FLIR Leptons

Display: OLED

Operating Temperature: -10° to +45° C

Refresh rate: 30Hz

Shutter: Yes

Accessories: Handle, Optional mounts

Features

Zeroable

On‑board image processing enhancement modes

Manual and automatic NUC capability

Temperature read‑out

Battery read‑out and protection

Auto power‑save

Multiple display views: white hot / color / black hot / NV green

Flexible mounting options: Tripod / Picatinny rail / user‑handle mount and more. Devices can be used in variety of search operations, firefighting and detection and other commercial applications
